10D API Rigid Spiral Casing Centralizer Integral Type Rigid Centralizer

Name: 10D API Rigid Spiral Casing Centralizer Integral Type Rigid Centralizer
Brand: PUYANGZHONGSHI
Price: 20 USD

Quality 10D API Rigid Spiral Casing Centralizer Integral Type Rigid Centralizer for sale

Brand Name : PUYANGZHONGSHI

Model Number : API or customized

Certification : API 5CT 1415，API 10D

Place of Origin : Puyang city , Henan province ,China

MOQ : 10pcs

Price : USD20-80$/pcs

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 1000pcs one month

Delivery Time : 15-20 work days

Packaging Details : wooden cases

Standard : API 5CT，API 10D

Type : Cementing tool

Size : 5 1/2--20''

Material : Spring Steel 65Mn, 65Mn Steel, or others

Color : Red

Contact Now

Centralizer introduction :

Casing centralizer is an important cementing tool which could help the casing put into the borehole smoothly and center the casing in the hole. The size of casing centralizer is 4" to 20". There are two kinds of bow spring centralizer and rigid centralizer.

10D API Rigid Spiral Casing Centralizer Integral Type Rigid Centralizer

Size Range

* The Single Piece Bow Spring Centralizers are available in sizes 4½" to 20".
* Any special sizes or combination can be made available on request.

Slip on Single Piece Casing Centralizer

API single piece centralizer performs satisfactorily in open hole as well as cased hole.These high quanlity product,developed to meet and exceed API 10D specifications for use in highly demanding downhole conditions.Single piece centralizer combines the highest restoring force with zero start force and zero running force.The single piece centralizer is used to position the casing in the center of the wellbore in vertical deviated and horizontal wells.

--------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

Size Range

Non-welded Hinged Bow Spring Centralizers are available in the sizes 2 ⅞" to 36"
Special sizes or combinations can be made available on request

Hinged Non-weld Bow Spring Centralizer

Hinged Non-welded Bow Spring Centralizer is used to position the casing in the centre of the wellbore in both vertical and
deviated wells. These Bow Spring Centralizers reduce the effect of channelling by improving cement flow. This results in a highly uniform thickness between the casing and the wellbore. These centralizers are able to minimise gas channeling by reducing the movement of the pipe before the cement sets in. Additionally, these bow spring centralizers provide a semi-rigid casing standoff.
A non-welded design features the self-locking of lips for holding bows to end collars. Bows of special alloy steel are hot-formed and then tempered for optimum strength, resilience, and uniformity.

---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

Size Range

* The Non welded hinged positive bow Simi Rigid centralizers are available in sizes 4 ½" to 30”
* Special sizes or combination can be made available on request

Hinged Non Welded Simi Rigid Casing Centralizer

Hinged Non Weld Semi Rigid Centralizers are uniquely designed with a flat-bottom U-profile of different depths, which permit an extremely high fluid passage. These positive centralizers may be used for both casing and tubing applications that require concentric casing strings. The straight bows provide nearly 100% stand-off (concentricity) when running inside a deviated cased hole, while the self-locking design of the centralizer ensures a firm hold. Furthermore, the non-welded structure eliminates brittle spots and enhances durability.

---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

Size Range

* Solid Rigid Stamped Casing Centralizers are available in sizes 4 ½" to 13 ⅜”
* Special sizes or combination can be made available on request
* Available with straight or spiral blades

(1) Welded casing centralizer

Weld casing centralizer specification

Model	Hooping In-Dia.	Hooping Thickness	Hooping Height	Total Length	Max. Out-Dia.	Spring Pieces
Model	Hooping In-Dia.	Hooping Thickness	Hooping Height	Total Length	Max. Out-Dia.	Spring Pieces
in	mm	mm	mm	mm	mm	pcs
5-1/2*8-1/2	142-148	5-7	50-60	650±50	225±5	5
6*8-1/2	154-158	5-7	50-60	650±50	255±5	5
13-3/8*17-1/2	342-349	8	50-60	580	450±5	6
20*26	510-518	8	50-60	650±50	670±5	10

(2) Non-welded casing centralizer

Non-weld casing centralizer specification

Model	Hooping In-Dia.	Hooping Thickness	Hooping Height	Total Length	Max. Out-Dia.	Spring Pieces
Model	Hooping In-Dia.	Hooping Thickness	Hooping Height	Total Length	Max. Out-Dia.	Spring Pieces
in	mm	mm	mm	mm	mm	pcs
5-1/2*8-1/2	142-148	3-5	90-120	650±50	225±5	5
7*9-5/8	181-186	3-5	90-120	650±50	255±5	6
7*8-1/2	181-186	3-5	90-120	650±50	235±5	6
8-5/8*12-1/4	223-228	3-5	90-120	650±50	330±5	8
9-5/8*12-1/4	250-255	3-5	90-120	650±50	330±5	8
10-3/4*12-1/4	274-276	3-5	90-120	650±50	330±5	9
13-3/8*17-1/2	342-347	3-5	90-120	650±50	450±5	11
18-5/8*24	476±1	3-5	90-120	600±50	610±5	12
20*26	510±1	3-5	90-120	600±50	660±5	12

FAQ

Q: Are you trading company or manufacturer ?

A: We are factory.

Q: How long is your delivery time?

A: Generally it is 1-5days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.

Q: What is your terms of payment ?

A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
